中华腔镜外科杂志(电子版) ›› 2026, Vol. 19 ›› Issue (04) : 238 -241. doi: 10.3877/cma.j.issn.1674-6899.2026.04.008

临床技术

无管化经皮经肝胆道镜取石术治疗肝胆管结石
朱灿华, 岑钧华, 汪国营†()
  1. 510120 广州医科大学第一附属医院
  • 收稿日期:2026-07-27 出版日期:2026-08-30
  • 通信作者: 汪国营

Tubeless percutaneous transhepatic cholangioscopic lithotomy for hepatolithiasis

Canhua Zhu, Junhua Cen, Guoying Wang†()

  1. The First Affiliated Hospital of Guangzhou Medical University, 510120, China
  • Received:2026-07-27 Published:2026-08-30
  • Corresponding author: Guoying Wang
引用本文:

朱灿华, 岑钧华, 汪国营. 无管化经皮经肝胆道镜取石术治疗肝胆管结石[J/OL]. 中华腔镜外科杂志(电子版), 2026, 19(04): 238-241.

Canhua Zhu, Junhua Cen, Guoying Wang. Tubeless percutaneous transhepatic cholangioscopic lithotomy for hepatolithiasis[J/OL]. Chinese Journal of Laparoscopic Surgery(Electronic Edition), 2026, 19(04): 238-241.

目的

探讨无管化经皮经肝胆道镜取石术的可行性及临床疗效。

方法

收集并总结2026年4月和2026年6月广州医科大学附属第一医院收治的2例肝胆管结石病患者,均接受无管化经皮经肝胆道镜取石术,分析2例患者临床一般资料、手术时间、手术方式、术中出血量、术后住院时间、术后并发症等指标。

结果

2例患者均采用超声引导下一步法完成经皮经肝胆管穿刺并扩张窦道取石,其中1例取净结石,留置8.5 Fr胆道内支架后直接拔除经皮肝鞘管,不留置经皮经肝胆道外引流管;另1例取净结石后采用可吸收人纤维蛋白粘合剂充填封闭肝窦道,不留置胆道内支架及胆道外引流,两例患者均实现无管化经皮经肝胆道镜取石。手术操作时间90 min和70 min,术中出血量均少于10 ml,术中、术后无胆道出血,腹腔积液,胆漏等并发症,术后复查腹部CT均无结石残留。

结论

无管化经皮经肝胆道镜取石术可一期取净结石,不留置胆道外引流管,为经皮经肝胆道镜治疗肝胆管结石病的治疗提供一种新的手术思路。

Objective

To explore the feasibility and clinical efficacy of tubeless percutaneous transhepatic cholangioscopic lithotomy.

Methods

Two patients with hepatolithiasis admitted to The First Affiliated Hospital of Guangzhou Medical University on Apr. 2026 and Jun. 2026 were enrolled in this study. Two patients underwent tubeless percutaneous transhepatic cholangioscopic lithotomy. Clinical baseline data, operative time, surgical procedures, intraoperative blood loss, postoperative hospital stay, postoperative complications of the two patients were analyzed.

Results

Ultrasound-guided one-step percutaneous transhepatic biliary puncture and sinus tract dilation for lithotomy were performed in both patients. Complete stone clearance was achieved in one case, an 8.5 Fr biliary internal stent was placed, then the percutaneous transhepatic sheath was removed without percutaneous transhepatic biliary external drainage. In the other case, after complete stone removal, the hepatic sinus tract was sealed with absorbable human fibrin glue, with neither biliary internal stent nor external biliary drainage placed. Tubeless percutaneous transhepatic cholangioscopic lithotomy was successfully accomplished in both patients. The operative time was 90 min and 70 min, respectively. Intraoperative blood loss was less than 10 ml in both cases. No intraoperative or postoperative complications such as biliary hemorrhage, peritoneal effusion or bile leakage occurred. Postoperative abdominal CT showed no residual stones in both patients.

Conclusion

Tubeless percutaneous transhepatic cholangioscopic lithotomy can achieve onestage complete stone clearance without placement of percutaneous transhepatic biliary external drainage tube. It provides a novel surgical strategy for percutaneous transhepatic cholangioscopic management of hepatolithiasis.

图1 留置胆道内支架的无管化经皮经肝胆道镜取石术注:A.术前肝8段胆管、右肝管结石;B.术前肝6段胆管结石;C.剑突下经皮经肝胆道硬镜取石术;D.网篮取出胆管结石;E.胆道内置入支架;F.取石后直接拔除鞘管,不留置胆道外引流;G.术后结石无残留,腹腔无积液;H.胆道内支架位置良好
图2 无管化经皮经肝胆道镜取石术注:A、B.术前肝内胆管多发结石(箭头);C.剑突下经皮经肝胆道硬镜取石术;D.肝窦道封堵装置(明胶海绵+人纤维蛋白粘合剂);E.胆道镜直视下将粘合剂(绿箭头)注入肝窦道直至肝表面(红箭头);F.取石后直接拔除鞘管,不留置胆道外引流;G.术后结石无残留;H.经皮经肝窦道(红箭头)封堵良好,腹腔无积液
[1]
Guo Q, Chen J, Pu T, et al. The value of three-dimensional visualization techniques in hepatectomy for complicated hepatolithiasis: A propensity score matching study[J]. Asian J Surg, 2023, 46(2): 767-773.
[2]
Wang P, Sun B, Huang B, et al. Comparison Between Percutaneous Transhepatic Rigid Cholangioscopic Lithotripsy and Conventional Percutaneous Transhepatic Cholangioscopic Surgery for Hepatolithiasis Treatment[J]. Surg Laparosc Endosc Percutan Tech, 2016, 26(1): 54-59.
[3]
朱灿华,王平,孙北望,等. 超声引导经皮肝Ⅰ期胆道造瘘联合硬质胆道镜治疗复杂肝胆管结石[J]. 中华肝胆外科杂志,2020, 26(2): 103-107.
[4]
Podda M, Polignano FM, Luhmann A, et al. Systematic review with meta-analysis of studies comparing primary duct closure and T-tube drainage after laparoscopic common bile duct exploration for choledocholithiasis[J]. Surg Endosc, 2016, 30(3): 845-861.
[5]
Guo Y, Guo X, Wang J, et al. Abdominal infectious complications associated with the dislocation of intraperitoneal part of drainage tube and poor drainage after major surgeries[J]. Int Wound J, 2020, 17(5): 1331-1336.
[6]
Wickham JE, Miller RA, Kellett MJ, et al. Percutaneous nephrolithotomy: one stage or two?[J]. Br J Urol, 1984, 56(6): 582-585.
[7]
中华医学会外科学分会胆道外科学组. 肝胆管结石病诊断治疗指南[J]. 中华消化外科杂志,2007, 6(2): 156-161.
[8]
中国研究型医院学会肝胆胰外科专业委员会,国家卫生健康委员会公益性行业科研专项专家委员会. 肝胆管结石病微创手术治疗指南(2019版)[J]. 中华消化外科杂志,2019, 18(5): 407-413.
[9]
中国研究型医院学会肝胆胰外科专业委员会. 肝胆管结石病经皮经肝取石手术应用指南(2021版)[J]. 中华肝胆外科杂志,2022, 28(1): 7-14.
[10]
Mukund A, Rana S, Choudhury A, et al. Outcome of percutaneous transhepatic biliary interventions in the management of biliary enteric anastomotic strictures with hepatolithiasis[J]. Clin Radiol, 2023, 78(1): e6-e12.
[11]
Wang S, Wu S. Percutaneous transhepatic choledochoscopy in the management of hepatolithiasis: a narrative review[J]. Quant Imaging Med Surg, 2024, 14(7): 5164-5175.
[12]
中国肝胆外科术中超声学院. 术中超声在胆道外科的应用中国专家共识(2022版)[J]. 中华肝胆外科杂志,2023, 29(1): 5-14.
[13]
张新洽,龚靖霖,王平,等. 左肝管与右肝管入路PTOBF取石手术治疗Ⅱa型肝胆管结石的比较研究[J]. 中华肝胆外科杂志,2024, 30(5): 360-364.
[14]
中华医学会超声医学分会介入诊疗学组. 超声引导经皮经肝胆管穿刺置管引流术中国专家共识(2023版)[J]. 中华超声影像学杂志,2023, 32(5): 369-376.
[15]
Zhao M, Zhang J, Zhang J, et al. Percutaneous Tract Embolization Versus Conventional Drainage Following Percutaneous Transhepatic Cholangioscopy for Biliary Stones[J]. J Evid Based Med, 2025: e70090.
[16]
中华医学会外科学分会胆道外科学组,中国医师协会外科医师分会胆道外科医师委员会. 胆道镜在肝胆管结石病诊断与治疗中的应用专家共识(2019版)[J]. 中华消化外科杂志,2019, 18(7): 611-615.
