中华腔镜外科杂志(电子版) ›› 2026, Vol. 19 ›› Issue (04) : 233 -237. doi: 10.3877/cma.j.issn.1674-6899.2026.04.007

论著

3D-CTBA指导下胸腔镜劈裂式肺段切除术治疗深部肺结节的安全性和可行性分析
薛青青, 徐文正, 潘相龙, 陈亮, 吴卫兵†()
  1. 210029 南京医科大学第一附属医院胸外科
  • 收稿日期:2026-07-21 出版日期:2026-08-30
  • 通信作者: 吴卫兵
  • 基金资助:
    江苏省卫生健康委医学研究重点项目(ZD2022055); 江苏省自然科学基金面上项目(BK20241985); 江苏大学临床医学科技发展基金项目(JLY2021144)

Safety and feasibility of 3D-CTBA-guided thoracoscopic split segmentectomy for deep pulmonary nodules

Qingqing Xue, Wenzheng Xu, Xianglong Pan, Liang Chen, Weibing Wu†()

  1. Department of Thoracic Surgery, First Affiliated Hospital with Nanjing Medical University, 210029, China
  • Received:2026-07-21 Published:2026-08-30
  • Corresponding author: Weibing Wu
引用本文:

薛青青, 徐文正, 潘相龙, 陈亮, 吴卫兵. 3D-CTBA指导下胸腔镜劈裂式肺段切除术治疗深部肺结节的安全性和可行性分析[J/OL]. 中华腔镜外科杂志(电子版), 2026, 19(04): 233-237.

Qingqing Xue, Wenzheng Xu, Xianglong Pan, Liang Chen, Weibing Wu. Safety and feasibility of 3D-CTBA-guided thoracoscopic split segmentectomy for deep pulmonary nodules[J/OL]. Chinese Journal of Laparoscopic Surgery(Electronic Edition), 2026, 19(04): 233-237.

目的

评价3D-CTBA指导下胸腔镜劈裂式肺段切除术治疗深部肺结节的可行性及围术期安全性。

方法

回顾性分析2020年1月至2024年12月单中心连续筛查行胸腔镜劈裂式肺段切除术患者的临床资料。深部肺结节定义为深度比>1/3。术前采用薄层CT及三维重建评估病灶与肺段、亚段支气管血管的空间关系,并以2 cm虚拟切缘球规划个体化切除范围;术中通过劈裂肺实质建立解剖通道,完成单一肺段或亚段切除,或肺段与亚段联合切除。观察手术计划完成情况、切缘距离及围术期结局。

结果

共筛查30例,排除外周肺结节6例,最终纳入24例。病灶最大径为(0.99±0.27)cm,深度比为(0.40±0.06)。共采用13种个体化切除方式,24例均按术前计划完成手术,无扩大切除或转行肺叶切除。切缘距离为(2.14±0.37)cm,手术时间为(143.0±46.2)min,术中出血量为(44.2±17.5)ml,术后住院时间为(3.33±0.84) d。持续漏气超过5 d者2例(8.3%),无再手术、再入院及30 d死亡。

结论

在严格病例选择和三维重建规划基础上,3D-CTBA指导下胸腔镜劈裂式肺段切除术治疗深部肺结节安全可行,可获得充分切缘。

Objective

To evaluate the feasibility and perioperative safety of three-dimensional computed tomography bronchography and angiography (3D-CTBA)-guided thoracoscopic split segmentectomy for deep pulmonary nodules.

Methods

Clinical data of consecutive patients screened for thoracoscopic split segmentectomy at a single center between Jan. 2020 and Dec. 2024 were retrospectively reviewed. A deep pulmonary nodule was defined as a nodule with a depth ratio >1/3. Preoperative thin-section computed tomography and three-dimensional reconstruction were used to assess the spatial relationships between the lesion and the segmental or subsegmental bronchi and vessels. A virtual 2-cm margin sphere was used to plan the individualized extent of resection. Intraoperatively, the lung parenchyma was split to establish an anatomical access route, followed by single segmentectomy or subsegmentectomy, or combined segmental and subsegmental resection. Outcomes included completion of the planned procedure, surgical margin distance, and perioperative outcomes.

Results

Thirty patients were screened, of whom 6 with peripheral pulmonary nodules were excluded, leaving 24 patients for analysis. The mean lesion diameter was 0.99±0.27 cm, and the mean depth ratio was 0.40±0.06. Thirteen individualized resection combinations were performed. All 24 procedures were completed as planned, without extended resection or conversion to lobectomy. The mean surgical margin distance was 2.14±0.37 cm, operative time was 143.0±46.2 min, intraoperative blood loss was 44.2±17.5 mL, and postoperative hospital stay was 3.33±0.84 days. Prolonged air leak lasting >5 days occurred in 2 patients (8.3%). No reoperation, readmission, or 30-day mortality was observed.

Conclusion

With strict patient selection and three-dimensional reconstruction-based planning, split segmentectomy is safe and feasible for deep pulmonary nodules and can achieve adequate surgical margins.

表1 患者基线特征及围术期资料
表2 个体化肺段及亚段切除范围
图1 右上肺结节影像、三维重建及手术图像注:A.CT图像和示意图显示结节位于右上叶深部;B.三维重建显示结节位于S1b和S3a之间;C.劈裂式S1b+S3a肺段切除后分离面显露;D.两侧保留肺组织S1a+S2和S3b充分复张
图2 右下肺结节影像、三维重建及手术图像注:A.CT图像和示意图显示结节位于右下叶深部;B.三维重建显示结节位于S9,同时靠近S8和S10;C.劈裂式S9+S10肺段切除后分离面显露;D.两侧保留肺组织S6和S7+S8充分复张
[1]
National Lung Screening Trial Research Team, Aberle DR, Adams AM, et al. Reduced lung-cancer mortality with low-dose computed tomographic screening[J]. N Engl J Med, 2011, 365(5): 395-409.
[2]
de Koning HJ, van der Aalst CM, de Jong PA, et al. Reduced lung-cancer mortality with volume CT screening in a randomized trial[J]. N Engl J Med, 2020, 382(6): 503-513.
[3]
Saji H, Okada M, Tsuboi M, et al. Segmentectomy versus lobectomy in small-sized peripheral non-small-cell lung cancer (JCOG0802/WJOG4607L): a multicentre, open-label, phase 3, randomised, controlled, non-inferiority trial[J]. Lancet, 2022, 399(10335): 1607-1617.
[4]
Altorki N, Wang X, Kozono D, et al. Lobar or sublobar resection for peripheral stage IA non-small-cell lung cancer[J]. N Engl J Med, 2023, 388(6): 489-498.
[5]
Ueda K, Tanaka T, Hayashi M, et al. What proportion of lung cancers can be operated by segmentectomy? A computed-tomography-based simulation[J]. Eur J Cardiothorac Surg, 2012, 41(2): 341-345.
[6]
He Z, Xu W, Li Z, et al. Thoracoscopic anatomical sublobar resection for deep interlobar lung cancer with fused fissure[J]. J Thorac Dis, 2024, 16(12): 8162-8172.
[7]
Li Z, He Z, Xu W, et al. Segmentectomy versus lobectomy for deep clinical T1a-bN0M0 non-small cell lung cancer[J]. Eur J Surg Oncol, 2023, 49(10): 106946.
[8]
Li Z, Xu W, Wang J, et al. Three-dimensional guided cone-shaped segmentectomy versus lobectomy for small-sized non-small cell lung cancer in the middle third of the lung field[J]. Ann Surg Oncol, 2023, 30(11): 6684-6692.
[9]
Pan X, Zhou S, Li Z, et al. Anatomical sublobar resection for multi-intersegmental pulmonary nodules[J]. Thorac Cancer, 2026, 17(3): e70216.
[10]
Xu W, Li Z, Zheng J, et al. Subsegment-based vs segment-based anatomical sublobar resection for lung cancer: a propensity score-matched analysis[J]. Ann Thorac Surg, 2026. DOI: 10.1016/j.athoracsur.2026.02.005.
[11]
Hong R, Chen C, Zheng W, et al. " Split" combined subsegmentectomy: a case series[J]. Thorac Cancer, 2022, 13(3): 423-429.
[12]
Takamori S, Oizumi H, Suzuki J, et al. Thoracoscopic "cut-through" segmentectomy for small-sized lung cancer in a deep central location[J]. Thorac Cancer, 2022, 13(24): 3510-3512.
[13]
Cao K, Zhu J, Zheng J, et al. Safety and efficacy of anatomical tunneling technique for precise lung segment resection in complex anatomical settings[J]. BMC Surg, 2024, 24(1): 409.
[14]
Brunelli A, Decaluwe H, Gonzalez M, et al. European Society of Thoracic Surgeons expert consensus recommendations on technical standards of segmentectomy for primary lung cancer[J]. Eur J Cardiothorac Surg, 2023, 63(6): ezad224.
[15]
Sawabata N, Ohta M, Matsumura A, et al. Optimal distance of malignant negative margin in excision of nonsmall cell lung cancer: a multicenter prospective study[J]. Ann Thorac Surg, 2004, 77(2): 415-420.
